Faqs

Q: When are fire doors required?
A: Basically wherever a fire might start, it is advisable to use a fire door. For example, doors leading from: a kitchen; a lounge with a fireplace & TV; or any room with electrical equipment or flammable items.

Building regulations for domestic properties stipulate when fire doors should be used and the key areas are:
  • If a 2 storey house has a door leading from an integral garage into the house it must be a fire door.
  • New build or renovated properties with 3 storeys or more, including loft conversions, must have FD30 fire doors to every habitable room off the stairwell.

Local councils issue planning permission and are responsible for policing building regulations through Building Control Officers. The architect who has specified the project is the best first point of call, regarding fire door requirements and regulations. Commercial property regulations are substantially different and it’s rare that a commercial building does not have some fire doors.


Q: How fire doors work?
A: A fire door must be fitted with approved intumescent strips which play a crucial part in achieving the fire door rating. When subjected to heat, the intumescent strips expand and seal the gap between the door edge and the frame. Intumescent seals can be fitted within the door frame or grooved into the door edge. Advice on the intumescent strips can be obtained from the test evidence report, which we can provide.

The material from which the door frame is constructed (e.g. softwood, hardwood or MDF), as well as its section sizes must comply with the required standards. Furthermore, essential hardware (ironmongery) must also have its’ own individual test evidence to show fitness for purpose.


Q: How is fire exit hardware different from panic hardware?
A: When panic hardware is used on fire doors, it must be fire exit hardware, which bears labels for both panic and fire resistance. A door with fire exit hardware will also have an additional label, indicating it is equipped with fire exit hardware. Fire exit hardware does not incorporate a mechanical dogging feature—the means to hold the latch retracted using a key, thumb turn, or Allen wrench. For fire doors where a ‘push/pull’ condition is desired, fire exit hardware with electric latch retraction may be used, as long as the latch projects automatically upon fire alarm, to secure the door.

Some vertical rod fire exit hardware for pairs of doors can be installed ‘less bottom rod’ (LBR). These devices use the top rod and latch only, with no bottom rod or latch. The advantage is there is no floor-mounted strike, and no bottom rod or latch to become damaged by carts or traffic. This configuration can sometimes cause a reduction in security, because it may be more easily defeated with only one latching point at the top of the door. In most cases, doors with LBR devices are required to have an auxiliary fire pin, which mounts in the edge of one door and projects into a hole in the edge of the other door if there is a fire.


Q: Do I need seals?
A:Yes, combined heat and smoke seals are designed to stop the spread of smoke and fire and to form a seal between your fire door and frame in a fire situation. As smoke is the leading cause of death in case of a fire the seals are an absolute must.


Q: What is the difference between an FD30 & FD60 fire door?
A:FD30 offers 30 minute fire protection and is suitable for all domestic situations. FD30’s are available in 44mm thickness. FD60’s offer 60 minute fire protection, these are available in 54mm thickness and are suitable for higher risk premises and some high risk rooms such as boiler rooms.


Q: Can I paint my fire door? A:Yes, you are able to paint or varnish your fire door with any good quality product.


Q: Can I have an external fire door with a veneer finish?
A: No, veneers are only suitable for internal purposes.


Q: Do I need a self-closer?
A: Yes, it is recommended that all fire doors are normally self-closing unless they are kept lock shut i.e. store rooms or cupboards.


Q: What are hinge pads?
A: Hinge pads are intumescent material used to prevent the hinge burning into the wood in a fire situation.


Q: Where is fire seals located?
A: If you purchase a lining/frame, these will be ready grooved for insertion of the seals. If you purchase a door only to fit into a suitable lining, we can router your door to accommodate the seals.


Q: Can I cut a fire door to size?
A: There are strict guidelines whereby only 3mm per side of a door and 5mm from the base can be trimmed.


Q: Do I need to use fire rated ironmongery?
A: Yes, we only provide recognized and board approved fire rated products.


Q: Which fire doors are compliant with the Disability Discrimination Act (DDA)?
A: DDA fire door must provide a minimum width of 900mm clearance and have suitably placed vision panels.


Q: What does standard door size mean?
A: There are 10 imperial standard sizes and 6 metric standard sizes for FD30 fire doors. FD60 fire doors have 4 imperial standard sizes and 4 metric standard sizes.


Q: Why do I have to wait for my fire door?
A: Most fire doors are made to order, however certain styles and standard sizes may be provided from stock.


Q: How heavy are fire doors?
A: FD30’s are approximately 45kg and FD60’s are upwards of 75kg.


Q: What is the largest fire door I can order?
A: The maximum size available is 2900mm x 2900mm.


Q: What is a paint grade ply finish?
A: Paint grade ply is a finish that would need to be primed and painted.


Q: What is a veneer book match?
A: Double fire door sets and fire doors in close proximity to each other may require a veneer match in order for the veneer to be evenly matched.


Q: What about certification?
A: Certification regarding the conformance with IS3614 part II tested at the Central Building and Research Institute


Q: What regulations affect the use of fire doors?
A: There are a number of regulations which apply to both new and existing buildings throughout the world. For new buildings (or those which include alterations, extensions or change of use) the Building Regulations apply.

The, recently updated, National Building Code 2016 consists of the regulations related to fire safety in its fourth part.


Q: Is intumescent required?
A:Yes, intumescent is required and will be provided when the fitting technician arrives on site for the fitting of the product


Q: Can the closer installation be reversed?
A: Yes. The closer can be installed in to the jamb however remember to reverse the fitting instructions included in the box.


Q: What is the difference between a smoke-stop door and a fire check/fire retardant door?
A: Smoke Stop door – Provides resistance only to the passage of smoke and other combustion products. NOT subject to the full severity of a fire because of their location Fire Check OR Fire Retardant Door – Requires resistance to the passage of smoke AND also blocks fire by containing it and compartmentalizing it. It has to meet both the requirements of smoke and flame resistance. At present, fire doors are specified as smoke-stop doors when required to fulfill the first function and fire-check and fire-resisting doors to fulfill the first and the second.


Q: Why Sehgal Fire Door is unique & trustworthy?
A: Light weight but heavy duty for rough & regular use.

  • Strongest & best in market.
  • Latest technique as per international standard.
  • All the components are imported.
  • All materials are non-toxin & environment friendly.
  • Our fire doors can be painted, polished or laminated as per customer’s requirement.

Q: Does double glazed glass get fog in between them and are they clear in view?
A:No, it doesn’t get any form of fog in between and the view is clear.


Q: What is the unsafe heat transfer rate that prevents human beings from passing through the evacuation lobby?
A: 140 ° Celsius


Q:What is the difference between a Fire Insulated and Non-insulated frame?
A: Insulated Door frame does not pass the temperature on exposed areas upto 140 ° Celsius, whereas Un-Insulated frames allow heat to transfer.


Q: Are we supplying a Fire Insulated Door? For how much time is it insulated?
A: Yes, manufacture both Insulated and uninsulated frame as per the client requirement.It is insulated upto 120min rating.


Q: What is the difference in GI & Steel door? Which is good for me?
A: GI is coated with zinc IS:277 whereas MS has no coating on it for which we have to add another protection coating on it.


Q: What are the infill materials inside doors?
A: For Fire Doors - Ceramic wool, Rock wool


Q: Can I use an AL frame for 120 Min fire protection? If not what is the reason?
A: No, because the Aluminium melting point is 660oCelsius and according to IS:3614 Part 2 the temperature of Fire at 120min is 1029o Celsius.


Q: Can I use a swing fire resistance door?
A: Yes only one side swing


Q: What is the maximum Width & Height of fire door tested against Fire Resistance?
A: Max Width 3000 mm, Max Height 3000 mm


Q: Can I touch the door handle after 60 Min of fire?
A: Yes only from the unexposed side.


Q: Why I should select steel door frames and shutters over wooden one?
A: Good quality wood is not available in our country. Apart from that, cutting of wood is now banned as it leads to deforestation and ultimately we lose our ecological balance. Steel is the safest and easily available material in our country. Steel door frames/shutters can be fabricated in any size and finish. Even, we can offer you steel door frames / shutters in wood finish also.


Q. Is it easy to fix steel door frames / Shutters?
A. Yes. Any technician can install steel door frames / shutters with holdfast else we provide them with fastener provision as well.


Q: Can I fix any kind of handles and locking system on steel door frames and shutters?
A: Yes. Any kind of lock and handles can be fixed on steel door frames and shutters. We are also flexible in providing hardware provision as per the Hardware shared by the client.


Q: Is it maintenance free?
A: Yes. Steel door frames/shutters are totally maintenance free. They can withstand in any weather condition compared to Wooden Doors.


Q: Can we change the original finish of frames?
A: Yes. You can repaint/spray finish the frames when needed.


Q: Can you give wood finish to door frames/shutters?
A: Yes. We can give wood finish to door frames/shutters.


Q: What is the specialty of Sehgal Doors Products?
A: Being machine made (on CNC Machines & Turret) quality and cutting of products is far superior compared to any other product.


Q: Can we use your products in green building?
A: Yes. Our products are suitable


Q: Does double glazed glass get fog in between them and are they clear in view?
A:No, it doesn’t get any form of fog in between and the view is clear.


Q: What is the unsafe heat transfer rate that prevents human beings from passing through the evacuation lobby?
A: 140 ° Celsius

Q:What is the difference between a Fire Insulated and Non-insulated frame?
A: Insulated Door frame does not pass the temperature on exposed areas upto 140 ° Celsius, whereas Un-Insulated frames allow heat to transfer.


Q: Are we supplying a Fire Insulated Door? For how much time is it insulated?
A: Yes, manufacture both Insulated and uninsulated frame as per the client requirement.It is insulated upto 120min rating.


Q: What is the difference in GI & Steel door? Which is good for me?
A: GI is coated with zinc IS:277 whereas MS has no coating on it for which we have to add another protection coating on it.


Q: What are the infill materials inside doors?
A: For Fire Doors - Ceramic wool, Rock wool


Q: Can I use an AL frame for 120 Min fire protection? If not what is the reason?
A: No, because the Aluminium melting point is 660 ° Celsius and according to IS:3614 Part 2 the temperature of Fire at 120min is 1029 ° Celsius.


Q: Can I use a swing fire resistance door?
A: Yes only one side swing


Q: What is the maximum Width & Height of fire door tested against Fire Resistance?
A: Max Width 3000 mm, Max Height 3000 mm


Q: Can I touch the door handle after 60 Min of fire?
A: Yes only from the unexposed side.
